Memory Retrieval Strategy Matters: A Comparative Study of Episodic Memory Backends for Reflexion-Style LLM Agents

Reflexion

Shinn et al. introduce Reflexion, in which an LLM agent verbalises lessons learned from task failures and stores them in an episodic buffer. Retrieved lessons augment the agent's context on subsequent attempts. The original work uses a fixed-size sliding window and evaluates on HotpotQA, AlfWorld, and HumanEval. Our work extends this by studying the memory component directly, treating retrieval strategy as the independent variable.

Memory-Augmented Language Agents

MemGPT proposes a hierarchical memory architecture for LLM agents, distinguishing in-context, external, and archival memory tiers. MemoryBank introduces long-term memory using vector retrieval for personalised LLM assistants. Park et al. demonstrate episodic memory retrieval in generative agent simulations. Our work differs in focus: we study how retrieval strategy interacts with the specific self-improvement mechanism of Reflexion, where retrieved content is verbal lessons rather than factual knowledge.

Retrieval-Augmented Generation

RAG systems retrieve external documents to augment LLM responses. Dense passage retrieval and contrastive learning-based embeddings underpin modern semantic retrieval. Our vector backend uses sentence-transformers for embedding reflection text, applying RAG principles to the agent self-improvement setting.

Tool-Use and Function Calling Benchmarks

The Berkeley Function-Calling Leaderboard (BFCL) provides standardised evaluation of LLM function-calling accuracy using AST matching. We evaluate on BFCL's multiple_function split, which requires the agent to select the correct function from a candidate set with similar signatures. Despite this harder disambiguation requirement, a 100% success@5 ceiling persists across all backends, indicating that GPT-4o solves these tasks reliably without needing memory-assisted iteration. Sequential multi-tool benchmarks such as ToolBench are likely needed to create the graded signal required for backend differentiation.

Multi-Step Reasoning

HotpotQA requires multi-hop reasoning over Wikipedia passages. We use the distractor setting, which provides 10 candidate passages per question, matching the format used by Reflexion.

Formal Framework

A memory backend B is a triple (store, retrieve, reset) operating over an episode set E. Each episode e is a 7-tuple:

The interface is defined as:

The three retrieval functions are defined as follows.

Sliding window returns the k most recent episodes by insertion order, ignoring the query entirely:

SQL filters by domain and orders failure episodes first. On attempt t ≥ 2 it additionally filters by the previous error type:

Vector DB retrieves the k nearest neighbours by cosine similarity above threshold θ:

where φ(·) is the all-MiniLM-L6-v2 embedding function and θ = 0.55.

We define signal density ρ as the fraction of retrieved episodes genuinely relevant to the current task T:

where relevant(e, T) = 1 if episode e contains a lesson applicable to task T, 0 otherwise. Section 5.1 uses this framework to characterise how ρ varies across backend classes as |E| grows.

Memory Backends

We implement three backends, each conforming to a common MemoryBackend interface with store(), retrieve(), and reset() methods.

Sliding Window (baseline). Episodes are stored in a Python list. retrieve(query, k) ignores the query entirely and returns the k most recent episodes. This mirrors the original Reflexion implementation. No persistence is used; all state is held in-process.

SQL (SQLite). Episodes are stored in a local SQLite database (zero external dependencies, sub-millisecond retrieval). retrieve(query, k) filters by domain and returns k episodes ordered success ASC, timestamp DESC: failures first, most recent first within each group. On attempt t ≥ 2, the actor calls retrieve_by_error_type(prev_error_type, k) to surface episodes sharing the exact failure mode of the previous attempt, falling back to general domain retrieval if fewer than k error-type matches exist.

Vector DB (ChromaDB). Episodes are embedded using all-MiniLM-L6-v2 from the sentence-transformers library. The embedded string is {domain}: {action_summary} -> {reflection}. retrieve(query, k) embeds the current task description and returns the k nearest neighbours by cosine similarity, subject to a minimum similarity threshold of 0.55. A persistent ChromaDB collection is used across tasks within a single experimental run.

Experimental Setup

Models. We evaluate two models to assess whether findings generalise across capability levels. The primary model is GPT-4o, used for all conditions. The secondary model is GPT-4o-mini, run on the reasoning domain only to test whether the SQL retrieval ordering effect is model-agnostic. Temperature is set to the API default (1.0) for both models.

Trial loop. Each task runs for up to 5 attempts. On each attempt: (1) the actor retrieves k=3 past reflections and generates a response; (2) the environment evaluates the response and returns (reward, success, feedback, error_type); (3) the reflector generates a verbal lesson; (4) the episode is stored in memory. The loop terminates on success or after 5 attempts.

Domains and benchmarks. Reasoning (HotpotQA): We sample 50 questions from the distractor validation split using a fixed seed. Reward is 1.0 for exact match, 0.5 for substring match, and 0.0 otherwise. Error types: exact_match, partial_match, wrong_answer. Tool-use (BFCL multiple_function): We use all 20 available tasks from the BFCL multiple_function split, which requires selecting the correct function from among candidates with similar names and signatures. The agent outputs Python function call syntax; correctness is evaluated by AST matching against the reference call. Reward is binary (1.0/0.0).

Infrastructure. SQLite is used in preference to hosted PostgreSQL to eliminate network latency as a confound in token and cost metrics, and to ensure full reproducibility from git clone with no credentials required. All experiments ran on a single machine; no distributed infrastructure was used.

Note on code domain. The HumanEval benchmark was excluded because its execution harness relies on signal.SIGALRM, which is unavailable on Windows. Results therefore cover two of the original three Reflexion domains.

Metrics

• success@k: fraction of tasks solved within k attempts.
• sample efficiency: number of episodes until 70% of tasks are solved (lower is better; ∞ if never reached).
• mean tokens per task: average total token consumption across all attempts for a task.
• cost per solved task: estimated USD cost ($0.005 per 1k tokens, blended GPT-4o rate) divided by number of solved tasks.

Statistical significance is assessed using the Wilcoxon signed-rank test on per-task binary success@5 scores, with p < 0.05 as the significance threshold.

Reasoning Domain (HotpotQA)

Results are shown in Table 1. Three findings stand out.

Vector DB leads on first-attempt success. Vec achieves 70.0% success@1 versus 58.0% for SW and both SQL variants, a 12 percentage point advantage. This is consistent with the semantic retrieval hypothesis: HotpotQA questions cluster by topic and reasoning pattern, so semantically similar past tasks share applicable lessons regardless of recency. The actor, presented with relevant prior reflections on attempt 1, resolves more tasks without needing any retry. Vec also achieves the lowest mean token count (3,621) and lowest cost per solved task ($0.0125), suggesting the retrieved reflections are high-signal enough to reduce response length and retry overhead.

Sliding Window leads on success@5. SW achieves 86.0% success@5, narrowly outperforming SQL-v2 and Vec (both 84.0%), though the difference is not statistically significant (p = 0.317, Wilcoxon). This is consistent with the dataset structure: with a fixed shuffle seed, similar HotpotQA question types cluster together in task order, making recent episodes incidentally relevant. This is a dataset artefact rather than a principled advantage of recency-based retrieval.

SQL-v1 significantly underperforms; SQL-v2 recovers. SQL-v1 achieves only 72.0% success@5, significantly below SW (p = 0.020) and Vec (p = 0.034). Post-hoc audit revealed the cause: SQL-v1's ORDER BY success DESC retrieval surfaced 351 of 353 retrieved episodes with error_type = exact_match (i.e. past successes). The agent was shown reminders of what had worked before rather than lessons from failures, effectively inverting the Reflexion mechanism. Correcting the ordering to success ASC, timestamp DESC (failure-first) recovers 12 percentage points, bringing SQL-v2 to 84.0%, which is statistically indistinguishable from Vec (p = 1.000). The SQL-v1 vs. SQL-v2 comparison is a controlled ablation: all other variables (schema, filtering logic, embedding, model) are held constant. Only retrieval ordering changes.

SQL Retrieval Ordering Ablation

Figure 1 shows the success curves for all four reasoning conditions across trial numbers 1–5. SQL-v1 diverges from the other backends at trial 2 and continues to lag throughout: tasks that reached attempt 2 were being shown successful past episodes rather than failure-specific lessons, preventing the agent from correctly diagnosing its error type. By trial 5, SQL-v1 has 15 tasks still failing (compared to 7 for SW and 8 for Vec/SQL-v2), all cycling through partial_match and wrong_answer errors without improvement.

This result has a practical implication: for any Reflexion-style system using structured memory, retrieval must prioritise failure episodes. Success episodes are valuable as few-shot exemplars but counterproductive for error diagnosis, which is what Reflexion's reflector requires.

Tool-Use Domain (BFCL multiple_function)

All three backends achieve 100% success@5 on the BFCL multiple_function split (n=20). Despite the harder disambiguation requirement, GPT-4o solves nearly all tasks on the first attempt: SW and Vec achieve 100% success@1, while SQL-v2 reaches 95% (19/20), with the one failure recovered by trial 2. The ceiling effect provides no signal for backend differentiation. SW achieves the lowest mean token cost (966 tokens per task, $0.0048 per solved task), but this advantage is attributable to task simplicity rather than retrieval efficiency.

Sample Efficiency

Vec requires only 48 episodes to reach 70% cumulative success on reasoning, compared to 88 for SQL-v2, 99 for SW, and 121 for SQL-v1. The large gap between Vec and SW (48 vs. 99 episodes) indicates that semantic retrieval produces meaningful signal earlier in the run, before the memory database is large enough for recency-based heuristics to work well. SQL-v1's 121-episode requirement reflects the warm-up confound: until approximately 20 tasks have been run, even failure-first ordering has few failure episodes to surface.

Model Generalisability (GPT-4o-mini)

To assess whether the retrieval ordering finding generalises beyond GPT-4o, we ran all three reasoning-domain conditions (SW, SQL-v2, Vec) using GPT-4o-mini on the same 50 HotpotQA tasks with the same fixed seed. Table 2 shows the results alongside GPT-4o baselines (in italics).

Two patterns emerge. First, first-attempt accuracy drops sharply across all backends: Vector DB suffers the largest single-shot degradation (−24pp at success@1, from 70.0% to 46.0%), while SW declines least (−8pp). This suggests that GPT-4o-mini extracts less value from semantically retrieved reflections on the first attempt, consistent with a weaker base capacity for context utilisation. Second, success@5 gaps narrow substantially: SW (−2pp), SQL-v2 (−4pp), Vec (±0pp). Vector DB is fully robust at the five-attempt ceiling, matching its GPT-4o performance exactly (84.0%).

The backend ranking at success@5 shifts modestly: with GPT-4o all three converge to 84–86%; with GPT-4o-mini, SW and Vec tie at 84.0% while SQL-v2 trails at 80.0%. The SQL failure-first ordering advantage, while preserved in direction, is smaller under GPT-4o-mini, suggesting the structured retrieval benefit scales with the model's capacity to apply failure-specific lessons.

Signal-to-Noise Framework

We propose a signal-to-noise framework for reasoning about memory backend choice in Reflexion systems. Define signal density as the fraction of retrieved episodes that are genuinely relevant to the current task and failure mode.

Sliding Window retrieval has high density for very small databases (every stored episode is recent and therefore likely relevant) but density degrades as the agent accumulates diverse experience. Recency and relevance are correlated only when task types cluster temporally, which is a dataset property rather than a retrieval property.

SQL maintains stable precision via structured filters (domain, error_type). Density does not degrade as the database grows because the filter scope constrains the candidate set. However, SQL cannot capture semantic similarity across tasks with different surface-form error types, and as our ablation shows, the ordering of results within the filtered set critically determines whether the agent receives useful error-diagnosis information.

Vector DB density peaks at medium database size (approximately 100–500 episodes in our experiments). At small sizes, high density is achieved trivially; at large sizes, noise from semantically adjacent but irrelevant episodes accumulates. The minimum similarity threshold of 0.55 partially mitigates degradation at scale.

Practical Recommendations

Based on our results, practitioners building Reflexion-style agents should:

1. 1Use failure-first retrieval ordering in any structured memory system. The SQL-v1 ablation shows that this single design decision accounts for a 12pp difference in success@5, larger than the difference between any two backend classes.
2. 2Prefer Vector DB for tasks with high semantic diversity (varied question types, diverse error distributions), where cross-task lesson transfer is valuable.
3. 3Prefer SQL for tasks with nameable, categorical error types (syntax errors, wrong tool selection) where structured credit assignment by error category outperforms semantic similarity.
4. 4Avoid sliding window as a default once the database exceeds approximately 50 episodes. Its performance on success@1 is dominated by both SQL-v2 and Vec, and it offers no mechanism for targeted error-type-based lesson retrieval.

Deployment Scenarios

These guidelines map onto concrete real-world settings.

Customer Support Agents. Customer support agents accumulate failure episodes as unresolved or incorrectly resolved tickets. Failure-first SQL retrieval means the agent surfaces lessons from structurally similar past failures rather than rehearsing what previously worked, directly addressing the pattern of repeating the same incorrect resolutions across semantically distinct queries. The error_type field in our schema maps naturally onto support taxonomies such as billing errors, account access failures, and policy misunderstandings, giving SQL's structured retrieval a well-defined signal to filter on.

Code Generation Pipelines. Code failures are precisely the kind of categorically nameable errors (syntax, runtime, type, wrong output) that SQL retrieval is designed for. An agent that has previously seen a NullPointerException in a similar context should retrieve that specific lesson rather than a recent reflection about an unrelated algorithmic task. The error-type retrieval path in our SQL implementation (retrieve_by_error_type) was built with this use case in mind.

RAG-Based Research and Document Assistants. These systems benefit most from Vector DB, specifically from its sample efficiency advantage. Our results show Vec reaching 70% cumulative success after only 48 episodes versus 99 for sliding window. In a fresh deployment with no prior episode history, this means a Vector DB-backed assistant becomes reliably useful roughly twice as fast as a recency-based one. For use cases where the agent encounters diverse question types across many topics (research assistance, technical documentation lookup, cross-domain QA), semantic similarity retrieval surfaces relevant past lessons even when surface-form phrasing and error categories differ across tasks.

The common thread across all three scenarios is that the value of a memory backend is determined not just by storage capacity but by retrieval precision under the specific failure distribution of the target task. Our signal-to-noise framework provides a principled basis for matching backend to deployment context before committing to infrastructure.

Limitations

Code domain excluded. HumanEval could not be evaluated on Windows due to the signal.SIGALRM dependency in the execution harness. This is the domain where SQL's retrieve_by_error_type (syntax vs. runtime vs. wrong output) was predicted to provide the largest advantage. A Linux or Docker environment is required to complete this evaluation.

Tool-use benchmark difficulty. Both BFCL splits tested (simple and multiple_function) exhibit a 100% success@5 ceiling across all backends, providing no signal for backend differentiation. Harder benchmarks are required: ToolBench G2/G3 multi-tool chains or API-Bank involve sequential tool use and partial rewards that would create the graded signal needed to distinguish memory backends.

Limited replications. Primary results (GPT-4o, all domains) reflect one random seed per condition. The GPT-4o-mini reasoning results provide a full replication across model capability levels, confirming the qualitative ordering of backends is preserved. Bootstrap confidence intervals are reported on within-condition task variance, but cross-seed variance for the primary conditions is not quantified. Three seeds per condition would provide more reliable estimates of backend-specific effect sizes and is a priority for future work.

Reflection quality not scored. The reflector's output quality (specificity, actionability, and accuracy) was not scored in these experiments. Reflection quality is the central mechanistic variable: better memory retrieval should produce higher-quality reflections, not just better task outcomes. Scoring a random sample would provide stronger mechanistic evidence for the semantic retrieval hypothesis.

k-ablation incomplete. The noise accumulation hypothesis — that Vector DB signal density ρ degrades beyond approximately 500 episodes as semantically adjacent but irrelevant episodes accumulate — could not be fully verified within the scope of these experiments. A systematic ablation varying k ∈ { 1, 3, 5, 10 } across database sizes of 50, 200, and 500 episodes is required to characterise the density-degradation curve and identify the optimal k as a function of |E|. The current fixed k=3 may underfit at small database sizes and overfit at large ones.
